Description

F-11 Plus 14-71 High-Helix Supercharger

Built for demanding high-performance applications, the F-11 Plus 14-71 Supercharger combines precision billet construction, advanced rotor geometry, and purpose-built internal components into a serious forced-induction package.

The F-11 is manufactured with precision CNC-machined and heat-treated components throughout, delivering the accuracy and durability required for demanding racing environments. At its core are form-tool-machined billet rotors, available in both 60-degree Standard Helix and 120-degree High-Helix configurations. This specification uses the High-Helix rotor design.

The blower incorporates substantial 3-inch-thick billet end frames, which are indexed and press-fit into the case for accurate assembly. Inside, precision caged roller and ball bearings support smooth operation, while double-lipped Teflon seals and full Teflon stripping provide effective sealing throughout the blower.

The F-11 also includes fuel cooling ports and a blower drive snout, with multiple snout lengths and configurations available to suit different installations. The result is a supercharger designed around the needs of serious builders who demand precision, robust construction, and configurable installation options.

Specifications
